Nexperia 74ABT125D,602, 4-Channel Non-Inverting 3 State Buffer, 14-Pin SOIC

Nexperia 74ABT125D,602, 4-Channel Non-Inverting 3 State Buffer, 14-Pin SOIC

Regular price €0,79 EUR
Regular price Sale price €0,79 EUR
Sale Sold out
Shipping calculated at checkout. Prices exclude VAT.

MPN: 74ABT125D,602

RS-ID: SKU:169-3524

Out of stock

Description

74ABT Family, Nexperia. Advanced BiCMOS Technology Logic Operating Voltage 4.5 to 5.0 Compatibility: Input LVTTL/TTL, Output TTL

Technical data
Characteristic Value
Logic Family ABT
Product Type Buffer
Logic Function Buffer & Line Driver
Number of Channels 4
Schmitt Trigger Input No
Input Type Single Ended
Output Type 3 State
Mount Type Surface
Polarity Non-Inverting
Minimum Supply Voltage 4.5V
Package Type SOIC
Pin Count 14
Maximum Supply Voltage 5.5V
Minimum Operating Temperature -40°C
Maximum Propagation Delay Time @ CL 4.6ns
Maximum High Level Output Current -32mA
Maximum Low Level Output Current 64mA
Maximum Operating Temperature 85°C
Series 74ABT125
Standards/Approvals No
Length 8.75mm
Height 1.45mm
Automotive Standard No
Supply Current 250μA
Datasheet
Manufacturer

Nexperia

Weight

2 G

Pack Size

1 unit = 1 units

Base Unit of Measure

PCE

Shipping

Expected availability from RS: currently unavailable
