MK Electric 13A 6 Gang Switched Fused Spur BS EN 61558-2-5:1998, BS 60669-2-4:2005, BS EN 60669-1:1999, BS 4573:1970,

MK Electric 13A 6 Gang Switched Fused Spur BS EN 61558-2-5:1998, BS 60669-2-4:2005, BS EN 60669-1:1999, BS 4573:1970,

€61,64 EUR
€61,64 EUR
Sale Sold out
Shipping calculated at checkout. Prices exclude VAT.

MPN: K961BSS

RS-ID: 169-1918

266 in stock
Description

MK Electric Fused SpurThe MK electric 2 gang surface mount fused spur has a current rating of 13A and 2-pole. The length and width of the fused spur is 86mm. It is designed for the connection of refrigerators, water heaters, central heating boilers, and other fixed appliances.Features and Benefits• Additional electrical safety from neutral ’make first, ’break last feature • Additional security (tamper proof version • All brass products are chemically treated • All supply and load cables can be cut and stripped to the same length • All terminal and fixing screws operated by one size (4mm) screw driver • Angled, top mounted terminal screws simplify wiring • Backed out and captive terminal screws • Captive fuse carrier • Fuse carrier lockable in open position • Hard wearing lacquer finish • Integrally wired indicators save installation time • Lacquered to minimise corrosion • Moulded ’on indicator flash on switches cannot rub off hence, its totally safe • Optional indicators in the switch rockers with 175° visibility in the horizontal and vertical planes • Push fit cord grips, for safer, quicker installation • Secure cable and flexible cord connection • Worm drive operated fuse carriers for 0Applications• Refrigerators • Water heaters • BoilersCertifications• ANSI/ESD S20.20:2014 • BS EN 61340-5-1:2007

Technical data
Characteristic Value
Product Type Fused Spur
Switched Yes
Number of Gangs 6
Current Rating 13A
Material Urea Moulded, Antimicrobial Property, High Grade Thermoset Material
Standards/Approvals BS EN 61558-2-5:1998, BS 60669-2-4:2005, BS EN 60669-1:1999, BS 4573:1970, IEC 60884-1:2006, BS EN 60670-22:2006, BS 1363 Pt 4:1995, BS 5733:2010, BS 546:1950, NF C61-314, BS 4177:1992, BS 1363 Pt 2:1995, BS 7288:1990, SASO 2204:2003, BS 4662:2006
Mount Type Surface, Flush
Colour White
Finish Gloss
Screwed/Screwless Screwless
Number of Poles 2
Depth 67mm
Range Logic PlusTM
Width 86mm
Series K961
Fixing Standard BS, SASO, IEC, BS EN, NF
Minimum Box Depth 35mm
Earth Terminal Yes
Faceplate Depth 15mm
Trip Current 30mA
Datasheet
Manufacturer

MK Electric

Weight

160 G

Pack Size

1 unit = 1 units

Base Unit of Measure

PCE
