Recom REC30-Z DC/DC Converter, 15V/ 1.34 A, 36V dc Input, 9V Input 30 W, Through Hole, 85 °C Max Temp -40 °C Min Temp,

Recom REC30-Z DC/DC Converter, 15V/ 1.34 A, 36V dc Input, 9V Input 30 W, Through Hole, 85 °C Max Temp -40 °C Min Temp,

€89,61 EUR
€89,61 EUR
Sale Sold out
Shipping calculated at checkout. Prices exclude VAT.

MPN: REC30-2412SZ

RS-ID: 100-2651

Low stock: 9 left
Description

IEC EN60950-01, UL60950, CSA C22.2 No.60950 ; EN55022 Certified. Recom REC30 Series Isolated DC-DC Converter. Recom REC30 series have been designed for use within higher power industrial applications. Boasting both single and dual regulated output functionality within a compact 2" x 1" package. The REC30 series also comes equipped with remote on/off control as standard to provide flexibility within applications. Another benefit of the REC20 series is track loss voltage compensation within the higher current output variants of the range. Features and Benefits. •Highly efficient range of DC-DC converters, boasting up to 90.5% efficiency. •External ON / OFF control for application flexibility. •Isolated to 1.6 k V dc. •Continuous short circuit protection. •6-side shielding.

Technical data
Characteristic Value
Product Type DC/DC Converter
Output Voltage 1 15V
Minimum Input Voltage 9V
Maximum Input Voltage 36V dc
Output Current 1 1.34A
Mount Type Through Hole
Input Ratio 4:1
MTBF 1541000h
Number of Outputs 1
Output Voltage Adjustment Range 10 %
Isolation Voltage 1.6kV dc
Number of Pins 8
Package Type SIP
Maximum Output Power 30W
Length 50.8mm
Depth 10.2mm
Width 40.6mm
Standards/Approvals No
Series REC30-Z
Maximum Operating Temperature 85°C
Efficiency 88.5%
Minimum Operating Temperature -40°C
Datasheet
Manufacturer

Recom

Weight

5 G

Pack Size

1 unit = 1 units

Base Unit of Measure

PCE
