Recom REC20 DC/DC Converter, 15V dc/ 1.34 A, 24V dc Input, 13.5V Input 20 W, Through Hole, 100 °C Max Temp -40 °C Min
Recom REC20 DC/DC Converter, 15V dc/ 1.34 A, 24V dc Input, 13.5V Input 20 W, Through Hole, 100 °C Max Temp -40 °C Min
MPN: REC20-2415S
RS-ID: SKU:100-2634
Out of stock
Couldn't load pickup availability
Description
IEC/EN60950-1, UL60950-1, CSA C22.2 No. 60950 ; EN55022 Certified. Recom REC20 Series Isolated DC-DC Converter. Recom REC20 series have been designed for use within higher power industrial applications. Boasting both single and dual regulated output functionality within a compact 2" x 1" package. The REC20 series also comes equipped with remote on/off control as standard to provide flexibility within applications. Another benefit of the REC20 series is track loss voltage compensation within the higher current output variants of the range. Features and Benefits. •Highly efficient range of DC-DC converters, boasting up to 90.5% efficiency. •External ON / OFF control for application flexibility. •Isolated to 1.6 k V dc. •Continuous short circuit protection. •6-side shielding.
Technical data
| Characteristic | Value |
|---|---|
| Product Type | DC/DC Converter |
| Output Voltage 1 | 15V dc |
| Minimum Input Voltage | 13.5V |
| Maximum Input Voltage | 24V dc |
| Output Current 1 | 1.34A |
| Mount Type | Through Hole |
| Input Ratio | 2:1 |
| MTBF | 607000h |
| Number of Outputs | 1 |
| Ripple and Noise | 100mV Pk-Pk |
| Output Voltage Adjustment Range | 10 % |
| Number of Pins | 6 |
| Isolation Voltage | 1.6kV dc |
| Package Type | Tube |
| Maximum Output Power | 20W |
| Standards/Approvals | CAN, CSA, cULus, EN55022, EN60950, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, IEC, IEC60950, IECEE CB Scheme, REACH, UL, UL60950 |
| Length | 50.8mm |
| Weight | 27g |
| Series | REC20 |
| Width | 25.4mm |
| Depth | 10.2mm |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | 100°C |
| Efficiency | 90% |
Datasheet
Manufacturer
Recom
Weight
5 G
Pack Size
1 unit = 1 units
Base Unit of Measure
PCE
