Texas Instruments 5 PWM Controller, 100 kHz 14V 16-Pin, MDIP - pack size 25 units

Texas Instruments 5 PWM Controller, 100 kHz 14V 16-Pin, MDIP - pack size 25 units

Regular price €2,03 EUR
Regular price Sale price €2,03 EUR
Sale Sold out
Shipping calculated at checkout. Prices exclude VAT.

MPN: LM78S40CN/NOPB

RS-ID: SKU:100-0725

175 in stock

Description

Maximum Switching Frequency = 100 kHz
Output Voltage = 40 V
Number of Outputs = 1
Mounting Type = Through Hole
Package Type = MDIP
Pin Count = 16
Dimensions = 19.05 x 6.35 x 3.3mm
Length = 19.05mm
Width = 6.35mm
Height = 3.3mm
Maximum Operating Temperature = +70 °C

Step-Down DC/DC Converters (Integrated Switch) over 35V Input Max., Texas Instruments

Technical data
Characteristic Value
Maximum Switching Frequency 100kHz
Product Type PWM Controller
Start-up Supply Current 1.8mA
Supply Current 1.8mA
Zero Power Detection No
Output Current 1.2A
Mount Type Through Hole
Package Type MDIP
Minimum Supply Voltage 2.7V
Maximum Supply Voltage 14V
Topology Buck
Pin Count 16
Maximum Duty Cycle 88%
Minimum Operating Temperature 0°C
Maximum Operating Temperature 70°C
PWM Controller Type Voltage Mode
Height 3.3mm
Series LM
Standards/Approvals No
Length 19.05mm
Automotive Standard No
Manufacturer

Texas Instruments

Weight

2 G

Pack Size

1 tu = 25 units

Base Unit of Measure

PCE

Shipping

2–3 days within Germany / 3–6 days within EU
