Vishay Single Layer Ceramic Capacitor 3.3 nF 40kV dc -20 to 80 % Y5U Dielectric, 715C, Screw 85 °C Max Op. Temp. - pack size 20 units
Vishay Single Layer Ceramic Capacitor 3.3 nF 40kV dc -20 to 80 % Y5U Dielectric, 715C, Screw 85 °C Max Op. Temp. - pack size 20 units
MPN: 715C40DKD33
RS-ID: SKU:169-3062
Out of stock
Couldn't load pickup availability
Description
Vishay 715C Series. Vishay 715C series are a high voltage ceramic disc capacitor with screw terminal mounting in an epoxy coated insulation that offers low inductance and high insulation resistance. The 715C series is suitable for a wide range of applications including industrial, high voltage power supplies, x-ray equipment and welding equipment. Screw terminal mounting High insulation resistance Low inductance Epoxy coated
Technical data
| Characteristic | Value |
|---|---|
| Product Type | Single Layer Ceramic Capacitor |
| Capacitance | 3.3nF |
| Voltage | 40kV dc |
| Mount Type | Screw |
| Series | 715C |
| Tolerance | -20 to 80 % |
| Automotive Standard | No |
| Dielectric | Y5U |
| Package/Case | 0814 |
| Minimum Operating Temperature | -30°C |
| Diameter | 58.4mm |
| Height | 34.5mm |
| Standards/Approvals | EC, RoHS, IEC 61249-2-21 |
| Suppression Class | Class II |
| Terminal Type | Screw |
| Dissipation Factor | 0.02% |
| Maximum Operating Temperature | 85°C |
Datasheet
Manufacturer
Vishay
Weight
0.005 G
Pack Size
1 bx = 20 units
Base Unit of Measure
PCE
Shipping
Expected availability from RS: 18.06.2026
