MK Electric 13A 6 Gang Switched Fused Spur BS 60669-2-4:2005, NF C61-314, BS 546:1950, BS EN 60669-1:1999, IEC

MK Electric 13A 6 Gang Switched Fused Spur BS 60669-2-4:2005, NF C61-314, BS 546:1950, BS EN 60669-1:1999, IEC

Regular price €64,85 EUR
Regular price Sale price €64,85 EUR
Sale Sold out
Shipping calculated at checkout. Prices exclude VAT.

MPN: K971BSS

RS-ID: SKU:169-1919

Low stock: 2 left

Description

Switched = Yes
Number of Gangs = 2
Current Rating = 13A
Number of Poles = 2
Length = 86mm
Width = 86mm
Fixing Standard = BS

MK Electric Fused SpurThe MK electric 2 gang surface mount fused spur has a current rating of 13A and 2-pole. The length and width of the fused spur is 86mm. It is designed for the connection of refrigerators, water heaters, central heating boilers, and other fixed appliances.Features and Benefits• Additional electrical safety from neutral ’make first, ’break last feature • Additional security (tamper proof version • All brass products are chemically treated • All supply and load cables can be cut and stripped to the same length • All terminal and fixing screws operated by one size (4mm) screw driver • Angled, top mounted terminal screws simplify wiring • Backed out and captive terminal screws • Captive fuse carrier • Fuse carrier lockable in open position • Hard wearing lacquer finish • Integrally wired indicators save installation time • Lacquered to minimise corrosion • Moulded ’on indicator flash on switches cannot rub off hence, its totally safe • Optional indicators in the switch rockers with 175° visibility in the horizontal and vertical planes • Push fit cord grips, for safer, quicker installation • Secure cable and flexible cord connection • Worm drive operated fuse carriers for 0Applications• Refrigerators • Water heaters • BoilersCertifications• ANSI/ESD S20.20:2014 • BS EN 61340-5-1:2007

Technical data
Characteristic Value
Switched Yes
Product Type Fused Spur
Number of Gangs 6
Current Rating 13A
Material High Grade Thermoset (Urea Moulded), Thermoset Material
Standards/Approvals BS 60669-2-4:2005, NF C61-314, BS 546:1950, BS EN 60669-1:1999, IEC 60884-1:2006, SASO 2204:2003, BS 4177:1992, BS EN 60670-22:2006, BS 1363 Pt 2:1995, BS 5733:2010, BS 7288:1990, BS EN 60669-2-1, BS EN 61558-2-5:1998, BS 1363 Pt 4:1995, BS 4573:1970
Mount Type Surface, Flush
Finish Gloss
Colour White
Screwed/Screwless Screwless
Number of Poles 2
Range Logic PlusTM
Depth 165mm
Trip Current 30mA
Earth Terminal Yes
Faceplate Depth 15mm
Fixing Standard BS, IEC, NF, BS EN, SASO
Width 86mm
Series K971
Minimum Box Depth 47mm
Datasheet
Manufacturer

MK Electric

Weight

160 G

Pack Size

1 unit = 1 units

Base Unit of Measure

PCE
