MK Electric 13A 6 Gang Switched Fused Spur BS 546:1950, BS 1363 Pt 2:1995, BS EN 60670-22:2006, BS EN 60669-2-4, BS

MK Electric 13A 6 Gang Switched Fused Spur BS 546:1950, BS 1363 Pt 2:1995, BS EN 60670-22:2006, BS EN 60669-2-4, BS

Regular price €44,40 EUR
Regular price Sale price €44,40 EUR
Sale Sold out
Shipping calculated at checkout. Prices exclude VAT.

MPN: K948BSS

RS-ID: SKU:169-1915

Low stock: 4 left

Description

Number of Poles = 2
Length = 86mm
Width = 86mm
Fixing Standard = BS

MK Electric Fused SpurThe MK electric 2 gang surface mount fused spur has a current rating of 13A and 2-pole. The length and width of the fused spur is 86mm. It is designed for the connection of refrigerators, water heaters, central heating boilers, and other fixed appliances.Features and Benefits• Additional electrical safety from neutral ’make first, ’break last feature • Additional security (tamper proof version • All brass products are chemically treated • All supply and load cables can be cut and stripped to the same length • All terminal and fixing screws operated by one size (4mm) screw driver • Angled, top mounted terminal screws simplify wiring • Backed out and captive terminal screws • Captive fuse carrier • Fuse carrier lockable in open position • Hard wearing lacquer finish • Integrally wired indicators save installation time • Lacquered to minimise corrosion • Moulded ’on indicator flash on switches cannot rub off hence, its totally safe • Push fit cord grips, for safer, quicker installation • Secure cable and flexible cord connection • Worm drive operated fuse carriers for 0Applications• Refrigerators • Water heaters • BoilersCertifications• ANSI/ESD S20.20:2014 • BS EN 61340-5-1:2007

Technical data
Characteristic Value
Product Type Fused Spur
Switched Yes
Number of Gangs 6
Current Rating 13A
Material Thermoset Material, High Grade Thermoset, Urea Moulded
Standards/Approvals BS 546:1950, BS 1363 Pt 2:1995, BS EN 60670-22:2006, BS EN 60669-2-4, BS 4573:1970, BS 5733:2010, SASO 2204:2003, IEC 60884-1:2006, BS 1363 Pt 4:1995, BS EN 60669-1:1999, NF C61-314, BS EN 61558-2-5:1998, BS 4177:1992
Mount Type Flush, Surface
Finish Gloss
Colour White
Number of Poles 2
Screwed/Screwless Screwless
Depth 32mm
Range Logic PlusTM
Width 86mm
Minimum Box Depth 25mm
Trip Current 30mA
Series K948
Fixing Standard BS, SASO, IEC, BS EN, NF
Faceplate Depth 15mm
Earth Terminal Yes
Datasheet
Manufacturer

MK Electric

Weight

155 G

Pack Size

1 unit = 1 units

Base Unit of Measure

PCE

Shipping

2–3 days within Germany / 3–6 days within EU
