STMicroelectronics B-LCDAD-HDMI1 DSI to HDMI Adapter Board for use with ST Discovery Kits
STMicroelectronics B-LCDAD-HDMI1 DSI to HDMI Adapter Board for use with ST Discovery Kits
MPN:
RS-ID: SKU:124-1571
1000 in stock
Couldn't load pickup availability
Description
The DSI to HDMI adapter board, part number B-LCDAD-HDMI1 is used for STM32 Development Boards or Discovery Boards. It comes with DSI input port and HDMI output port. What is the benefit of B-LCDAD-HDMI1? B-LCDAD-HDMI1 includes bridge chip ADV7533, therefore this board can support 2-, 3- or 4-lanes DSI video input data, S/PDIF, 2-channels I2S audio input data and HDMI v1.3 output port. What is STM32 Development Board? These boards have been designed for development purposes for the ARM Cortex STM32 MCUs. STM32 carries external circuity such as transceivers, sensors, memory interfaces, displays and many more and are known as a reference design for application development. Features of B-LCDAD-HDMI1: • Up to four lanes of MIPI/DSI data, each running up to 800 Mbps • 2-channels I2S transmits stereo up to 192 kHz sampling rate • S/PDIF carries stereo LPCM audio or compressed audio HDMI output connector: • Support of video resolutions with pixel clocks up to 80 MHz • Support of CEC signals, 5 V-tolerant I2C and HPD I/Os • Common-mode filters with ESD protection Application: • Development Design • Embedded Design
Technical data
| Characteristic | Value |
|---|---|
| Product Type | Development Kit Accessory |
| Accessory Type | DSI to HDMI Adapter Board |
| For Use With | ST Discovery Kits |
| Standards/Approvals | HDMI v1.3 |
Datasheet
Weight
16.000 G
Pack Size
1 unit = 1 units
Base Unit of Measure
PCE
Shipping
Expected availability from RS: currently unavailable
