Omron G3PJ Series Solid State Relay, 15 A Load, DIN Rail Mount, 528 V ac Load, 24V dc Control

Omron G3PJ Series Solid State Relay, 15 A Load, DIN Rail Mount, 528 V ac Load, 24V dc Control

€0,00 EUR
€0,00 EUR
Sale Sold out
Shipping calculated at checkout. Prices exclude VAT.

MPN:

RS-ID: 111-3040

1000 in stock
Description

G3PJ-515B-PU DC12-24 SSR – Slim Design, Single-Phase Low Heat Generation Solid State Relay. Make the most of your control panels and increase their value with the single-phase solid state relay. Low heat generation means you can carry 25 A, even when close mounting. The slim design and easy wiring enables you to downsize your control panels and cooling equipment. RoHS compliant. Features and Benefits of G3PJ-515B-PU DC12-24 Slim SSR –Solid State Relay. • Push-In terminals, input. • Screw terminals , output • Single-phase relay. • Phototriac coupler. • Orange LED indicator. • Rated output voltage 12 to 24 V dc. • Zero cross function. • Rated load voltage 100 to 480 V ac. • Slim design. • Easy wiring. • Can be close mounted. • Low heat generation. Rated Load Current of the SSR - Relay at 40°C Ambient Temperature (dependant on ambient temperature). • Close mounting for three SSR – Solid state relays – 15 A • Separate mounting 23 A. SSR – Solid State Relay Input Rating at 25°C. • Operating voltage range 9.6 to 30 V dc. • Current 7 mA max. • Must operate voltage 9.6 V dc max. • Must release voltage 1 V dc min. SSR – Solid State Relay Output. • Rated load voltage 100 to 480 V ac, 50 / 60 Hz. • Load voltage range 75 to 528 V ac, 50 / 60 Hz. • Inrush resistance 150 A, 60 Hz, 1 cycle. • 1350A²S. Additional Features G3PJ-515B-PU DC12-24 Slim, SSR – Solid State Relay. • Operate and release time of load power source cycle + 1 ms max. • Output ON voltage drop 1.8 V (RMS) max. • Leakage current 20 mA max at 240 V ac. • Vibration resistance 10 to 55 to 10 Hz, 0.35 single amplitude, 0.7 mm double amplitude, DIN rail mounted. • Shock resistance, destruction, 300 m/s², DIN rail mounted. • Operating temperature, ambient, -30°C to 80°C, no icing or condensation. • Relay weight 240 g. • SCCR (UL508) 10 kA. What does Zero Cross Function mean in SSR in Solid State Relays? Zero cross function will allow the relay to turn ON when the AC load power supply approaches 0 V suppressing any noise generated with a sudden load current increase. Zero cross function is effective across 2 types of noise, noise on power lines and noise emitted into open space.

Technical data
Characteristic Value
Maximum Load Current 15A
Product Type Solid State Relay
Mount Type DIN Rail, Screw
Maximum Load Voltage 528V ac
Minimum Load Voltage 75V ac
Maximum Control Voltage 24V dc
Minimum Control Voltage 12V dc
Series G3PJ
Terminal Type Push-in
Contact Configuration SP
Switching Function Zero Cross Switching
Minimum Operating Temperature -30°C
On State Resistance 100mΩ
Maximum Operating Temperature 80°C
Height 100mm
Width 22.5mm
Standards/Approvals TUV, cULus, CE
Length 22.5mm
Output Type Triac
Off State Leakage Current 20mA
Datasheet
Weight

232.000 G

Pack Size

1 unit = 1 units

Base Unit of Measure

PCE
