Omron G3RV-SR Solid State Interface Relay 18V dc, 30 V dc DIN Rail Screw

Description

G3RV-SR700-A AC230 – I/O Low Profile SSR - Solid State Relay 6.2 mm Wide. This I/O SSR-Solid state relay has a lower profile up to 25% of other standard SSR allowing further downsizing of the control panel. An optimal slim design relay that includes high frequency and high speed opening and closing of the SSR –solid state relay. Features and Benefits G3RV-SR700-A AC230 I/O Slim SSR – Solid State Relay. • Screw terminal. • 60% Reduced wiring time. • AC Applicable output load. • Zero cross function. • Rated input voltage 230 V ac. • Slim compact design. • AC output – Triac. • High frequency. • High speed opening and closing. • Easy wiring. SSR – Solid State Relay Input Rating at ambient 25°C. • Rated current AC – 7.5 mA 50 Hz, 8.8 mA 60 Hz. • Must operate voltage 207 V max. • Must release voltage 1 V min. • Input voltage ±10% of rated voltage. SSR – Solid State Relay Output. • Rated load voltage 100 to 240 V ac, 50/60 Hz. • Load voltage range 75 to 264 V ac, 50/60 Hz. • Load current 0.1 to 2 A at ambient temperature 25°C. 100 μA to 3 A at an ambient 25°C. • Inrush current resistance 30 A, 60 Hz, 1 cycle. • Applicable load capacity 400 W, output voltage 200 V ac. Additional Features of G3RV-SR700-A AC230 SSR – Solid State Relay. • Operate time 1/2 cycle of load power supply +1 ms max. • Release time 60 ms max. • Output ON voltage drop 1.6 V (RMS) max. • Leaked current 5 mA max at 200 V ac, 50/60 Hz. 10 μA max at 24 V dc. • Vibration resistance – malfunction 10 to 55 to 10 Hz double amplitude. • Shock resistance 300 m/s². • Ambient operating temperature -30°C to +55°C. • Relay weight 38 g. • IP 20 • Load category LC-A. • Rated insulation voltage 240 V. Suitable SSR – Solid State DIN Rails. • Part number PFP-100N – 1 m DIN relay, Stock number (8278403) 8278403. • Part number PFP-50N – 0.5 m DIN relay, Stock number (8278400) 8278400. Suitable End Plate for the SSR –Solid State Relay. • Part number PFP-M, stock number (8278419) 8278419. Suitable Spacer Plate for the SSR- Solid State Relay. • Part number PFP-S, Stock number (8278412) 8278412. What does Zero Cross Function mean in SSR in Solid State Relays? • Zero cross function will allow the relay to turn ON when the AC load power supply approaches 0 V suppressing any noise generated with a sudden load current increase. Zero cross function is effective across 2 types of noise, noise on power lines and noise emitted into open space.

Technical data

Datasheet

• Datasheet

Weight

29.000 G

Pack Size

1 unit = 1 units

Base Unit of Measure

PCE

Shipping

Expected availability from RS: currently unavailable
